| Product Name | Ihold (A) |
Itrip (A) |
Vmax (Vdc) |
Imax (A) |
Pdtyp. (W) |
Maximum Time To Trip Current (A) |
Maximum Time To Trip Time (Sec.) |
Rmin (Ω) |
Rmax (Ω) |
R1max (Ω) |
Data Sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
SC600-110SW0D
|
0.11 | 0.22 | 220 | 3.0 | 1.5 | 0.55 | 5.0 | 10.0 | -- | 28.5 |
|
SC600-375SZ0D
|
0.375 | 0.75 | 400 | 3.0 | 3.5 | 1.875 | 30.0 | 2.5 | -- | 6.75 |
|
SC600-150SW0D
|
0.15 | 0.30 | 400 | 3.0 | 1.5 | 0.75 | 5.0 | 6.0 | 12.0 | 18.0 |
|
|
SC600-200SW0D
|
0.20 | 0.40 | 400 | 3.0 | 1.5 | 1.0 | 10.0 | 5.0 | 9.0 | 14.0 |
|
|
SC600-500SZ0D
|
0.50 | 1.00 | 400 | 3.0 | 1.5 | 2.50 | 15.0 | 0.6 | -- | 1.5 |
|
